PART NO. THREAD O-RING DIMENSIONS E F E A B L S1 1EL-14 M14X1.5 M14X1.5 10X1.9 11 12 30.5 19 1EL-14-16 M14X1.5 M16X1.5 10X1.9 11 12 31 22 1EL-14-18 M14X1.5 M18X1.5 10X1.9 11 12 32.5 24 1EL-14-22 M14X1.5 M22X1.5 10X1.9 11 14 36.5 27 1EL-16-14 M16X1.5 M14X1.5 11X1.9 11 12 29 19 1EL-16-18 M16X1.5 M18X1.5 11X1.9 11 12 31 24 1EL-22-18 M22X1.5 M18X1.5 16X2.4 12 12 33.5 24 1EL-27-22 M27X1.5 M22X1.5 18X2.4 13 14 38.5 30 1EL-27-33 M27X1.5 M33X2 18X2.4 13 18 44
41 1EL-30-18 M30X1.5 M18X1.5 24X2.4 14 12 38.5 32 1EL-30-27 M30X1.5 M27X2 24X2.4 14 16 41 34 1EL-36-33 M36X2 M33X2 30X3.1 16 18 49 41 1EL-36-48 M36X2 M48X2 30X3.1 16 22 53 60 1EL-45-42 M45X2 M42X2 38X3.1 21 20 56 50 1EL-52-48 M52X2 M48X2 40X3.1 22 22 61 60 Note:The parameter of E end O-Ring is ring outside diameter and ring width.
PEHEL | Metric Male O-Ring to Metric Male Bonded Seal Adapter, Hydraulic Thread Fitting
PEHEL Hydraulic Model: 1EL
QTY:
Type: Metric Male O-Ring to Metric Male Bonded Seal Adapter
End 1: Metric Male with O-Ring
End 2: Metric Male with Bonded Seal
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc-plated
1.Metric male O-ring to metric male bonded seal adapter, designed for transitioning between two metric male threaded connections with different sealing methods.
2.O-ring end features an integrated O-ring for sealing against a flat face or chamfered port.
3.Bonded seal end uses a bonded washer with a rubber insert for sealing against a flat port face.
4.Both ends have metric male threads, providing secure engagement with corresponding female threaded ports.
5.Manufactured from high-strength carbon steel with anti-rust surface treatment for durability.
