PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C H S1 S2 28641-14-04 M14X1.5 6 04 43.5 11 21.3 19 19 28641-16-05 M16X1.5 8 05 47.5 10.5 24.3 22 22 28641-18-06 M18X1.5 10 06 49.5 11 25 24 24 28641-22-08 M22X1.5 12 08 62 14 27.2 27 27 28641-24-10 M24X1.5 16 10 74.5 14.5 30 32 32 28641-30-12 M30X1.5 20 12 81 17 33.5 36 36 28641-33-16 M33X1.5 25 16 90.7 17.5 35.7 41 41 28641-36-20 M36X1.5 32 20 104.5 18 42 46 46 28641-42-24 M42X1.5 40 24 117 19 47.5 55 55 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 28642-XX-XX。
PEHEL | 45° JIS Metric Female 60° Cone Seat Fitting, Hydraulic Elbow Fitting
PEHEL Hydraulic Model: 28641
QTY:
28641 Japanese Metric 45° Elbow Male Fittings, 60° Cone Seat
Type: 45° JIS Metric Female 60° Cone Seat Fitting
Angle: 45° Elbow
Thread: Metric Female
Sealing: 60° Cone Seat
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc-plate
1.45° JIS metric female 60° cone seat fitting, designed as an angled hydraulic fitting with a 60° cone sealing surface.
2.Female metric threads allow secure engagement with corresponding male threaded components.
3.The 60° cone seat provides metal-to-metal sealing through line contact when mated with a matching cone.
4.45° elbow configuration enables directional change of fluid flow in confined spaces.
5.Manufactured from high-strength carbon steel with anti-rust surface treatment for durability.
