Metric Maile 24º Cone Seat H.T.

Metric Maile 24º Cone Seat H.T.

PEHEL Hydraulic Model: P10512

QTY:

Hydraulic 10512 metric male 24° cone seat H.T.

  • Metric Maile 24º Cone Seat H.T. Specification
  • You May Also Like
  • PART NO. THREAD E HOSE BORE TUBE O.D. DIMENSIONS
    DN DASH C S1
    P10512-16-04 M16X1.5 6 04 8 13.5 17
    -18-04 M18X1.5 6 04 10 13.5 19
    -20-05 M20X1.5 8 05 12 13.5 22
    -20-06 M20X1.5 10 06 12 13.5 22
    -22-06 M22X1.5 10 06 14 14 24
    -24-08 M24X1.5 12 08 16 14 27
    -30-10 M30X2 16 10 20 19 32
    -30-12 M30X2 20 12 20 19 32
    -36-12 M36X2 20 12 25 20 38
    -36-16 M36X2 25 16 25 20 38
    -42-12 M42X2 20 12 30 20 46
    -42-16 M42X2 25 16 30 20 46
    -42-20 M42X2 32 20 30 20 46
    -52-16 M52X2 25 16 38 22 55
    -52-20 M52X2 32 20 38 22 55
