PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C S2 26713-12-12W 1.1/16"X12 20 12 22.5 14.5 32 26713-16-16W 1.5/16"X12 25 16 25.8 15.6 41 26713-20-20W 1.5/8"X12 32 20 26.5 16.1 50 26713-24-24W 1.7/8"X12 40 24 27.8 19.5 55 26713-32-32W 2.1/2"X12 50 32 34.5 23.6 75
Pehel | 26713‑W JIC Straight Female 74°Cone Hydraulic Fitting
PEHEL Hydraulic Model: P26713-W
QTY:
26713-W JIC Straight Female 74° Cone Fittings
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type: JIC Straight Female 74° Cone
Thread Type: JIC 74° cone thread standard
About the item:
- 1.26713‑W JIC straight female 74° cone fitting built for standard JIC hydraulic hose assembly connections
- 2.Precision machined 74° cone seat of this JIC female fitting ensures leak‑tight high‑pressure sealing
- 3.Silver zinc‑plated surface on 26713‑W JIC straight fitting offers reliable rust‑resistance in harsh working conditions
- 4.High strength carbon steel construction makes the JIC 74° cone fitting stable under heavy hydraulic pressure
- 5.Pehel supports OEM service for 26713‑W JIC straight female fitting to match custom hydraulic requirements
- 6.Accurate thread tolerance of JIC 74° cone fitting enables quick and hassle‑free field installation
