Home    >     Hose Fitting    >    American Standard    >     JIC 74° Cone Seal    >     90º JIC FEMALE 74º CONE SEAT

90º JIC FEMALE 74º CONE SEAT

Model: P26792

QTY:

  • You May Also Like

  • PART NO. THREAD E HOSE BORE DIMENSIONS
    DN DASH C S2 H
    P26792-04-04 7/16"x20 6 04 9 17 33.5
    -06-06 9/16"x18 10 06 10.5 19 39.3
    -08-08 3/4"x16 12 08 10.5 24 47
    -10-10 7/8"x14 16 10 12 27 52.5
    -12-12 1.1/16"x12 20 12 15 32 63.5
    -16-16 1.5/16"x12 25 16 16 41 70
    -20-20 1.5/8"x12 32 20 17 50 82.5
    -24-24 1.7/8"x12 40 24 20 60 97.5
    -32-32 2.1/2"x12 50 32 24.5 75 118.8
