PART NO. THREAD DIMENSIONS E F A B S1 P1JN4-04 7/16"X20 Z1/4"X18 22.3 21 14 P1JN4-05-04 1/2"X20 Z1/4"X18 22.3 21 14 P1JN4-06 9/16"X18 Z3/8"X18 25 29.5 22 P1JN4-08 3/4"X16
Z1/2"X14 28 29.5 22 P1JN4-10-08 7/8"X14 Z1/2"X14 31 29.5 22 P1JN4-12 1.1/16"X12 Z3/4"X14 35.5 35 27 P1JN4-16 1.5/16"X12 Z1"X11.5 38.5 39 33
PEHEL/45º ELBOW JIC Male 74º CONE/NPT MALE ADAPTER
PEHEL Hydraulic Model: P1JN4-2503
QTY:
45º ELBOW JIC Male 74º CONE/NPT MALE ADAPTER
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: CONNECT WITH JIC FEMALE AND NPT FEMALE
Thread Type 1: NPT MALE
Thread Type 2: JIC MALE
About the item:
1. Model P1JN4-2503 is a 45-degree hydraulic elbow adapter with dual male threads: JIC 74° cone flare and NPT taper thread.
2. Matches standard SAE J514 74° metal-to-metal cone sealing, delivering stable leak-proof performance under high hydraulic pressure.
3. Complete size lineup covering JIC threads from 7/16"×20 to 1-5/16"×12 and corresponding NPT thread specifications.
4.Equipped with matched nut and sleeve assembly, standardized A/B/S1 dimensional data for fast and accurate field installation.
5. Ideal transition connector for cross-standard hydraulic pipelines, widely applicable to industrial and mobile hydraulic equipment.
