PART NO. THREAD O-RING DIMENSIONS E F G F A B C S1 S2 AJHJ-04-10-04OG 7/16"X20 M10X1 7/16"X20 8.1X1.6 24.5 26.5 24.5 11 14 AJHJ-04-12-04OG 7/16"X20 M12X1.5 7/16"X20 9.3X2.4 26.6 32 26.6 14 17 AJHJ-05-10-05OG 1/2"X20 M10X1 1/2"X20 8.1X1.6 26.6 28.8 26.6 14 14 AJHJ-05-12-05OG 1/2"X20 M12X1.5 1/2"X20 9.3X2.4 26.6 32 26.6 14 17 AJHJ-05-14-05OG 1/2"X20 M14X1.5 1/2"X20 11.3X2.4 26.6 32 26.6 14 19 AJHJ-06-14-06OG 9/16"X18 M14X1.5 9/16"X18 11.3X2.4 26.9 32 26.6 14 19 AJHJ-06-16-06OG 9/16"X18 M16X1.5 9/16"X18 13.3X2.4 28.5 34.8 28.5 16 22 AJHJ-08-16-08OG 3/4"X16 M16X1.5 3/4"X16 13.3X2.4 32 36 32 19 22 AJHJ-08-18-08OG 3/4"X16 M18X1.5 3/4"X16 15.3X2.4 32 37 32 19 24 AJHJ-10-18-10OG 7/8"X14 M18X1.5 7/8"X14 15.3X2.4 37.8 39.5 37.8 22 24 AJHJ-10-22-10OG 7/8"X14 M22X1.5 7/8"X14 19.3X2.4 37.8 40.2 37.8 22 27 AJHJ-12-22-12OG 1.1/16"X12 M22X1.5 1.1/16"X12 19.3X2.4 44.2 43.5 44.2 27 27 AJHJ-12-27-12OG 1.1/16"X12 M27X2 1.1/16"X12 23.5X3 44.2 48.5 44.2 27 32 AJHJ-16-27-16OG 1.5/16"X12 M27X2 1.5/16"X12 23.5X3 49 52 49 33 32 AJHJ-16-33-16OG 1.5/16"X12 M33X2 1.5/16"X12 29.2X3 49 52.5 49 33 41 AJHJ-20-42-20OG 1.5/8"X12 M42X2 1.5/8"X12 38.5X3 55.5 57.2 55.5 41 50 AJHJ-24-48-24OG 1.7/8"X12 M48X2 1.7/8"X12 44.5X3 62.5 62.7 62.5 48 55 Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
Pehel/AJHJ-OG/Carbon Steel Male JIC 74deg Cone-Metric O-ring-JIC 74deg Cone Tee Adapter With Adjustable Nut
PEHEL Hydraulic Model: AJHJ-OG
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Tee
Thread Type: JIC/metric O-ring
About the item:
1.Interchangeable with ISO 8434 standard counterparts, no custom modification required for direct replacement in existing hydraulic systems.
2.Zinc-plated carbon steel body with salt spray resistance up to 240 hours, effectively preventing corrosion in outdoor and humid working environments.
3.Wide operating temperature range from -40℃ to +120℃, stable performance in extreme cold northern mines and high-temperature metallurgy workshops.
