PART NO. THREAD DIMENSIONS E F A B L S1 S2 2JB-04 7/16"X20 G1/4"X19 14 5.5 31 12 19 2JB-04-02 7/16"X20 G1/8"X28 14 5.5 29 14 14 2JB-04-06 7/16"X20 G3/8"X19 14 6.3 32.5 17 22 2JB-05-02 1/2"X20 G1/8"X28 14 5.5 29 14 14 2JB-05-04 1/2"X20 G1/4"X19 14 5.5 31 14 19 2JB-06 9/16"X18 G3/8"X19 14.1 6.3 32.5 17 22 2JB-06-04 9/16"X18 G1/4"X19 14.1 5.5 31 17 19 2JB-06-08 9/16"X18 G1/2"X14 14.1 7.5 34 19 27 2JB-08 3/4"X16 G1/2"X14 16.7 7.5 38.5 22 27 2JB-08-04 3/4"X16 G1/4"X19 16.7 5.5 35.5 22 19 2JB-08-06 3/4"X16 G3/8"X19 16.7 6.3 37 22 22 2JB-08-12 3/4"X16 G3/4"X14 16.7 10.9 42 27 32 2JB-10 7/8"X14 G5/8"X14 19.3 9.5 42 24 30 2JB-10-08 7/8"X14 G1/2"X14 19.3 7.5 41 24 27 2JB-12 1.1/16"X12 G3/4"X14 21.9 10.9 47 30 32 2JB-12-08 1.1/16"X12 G1/2"X14 21.9 7.5 46 30 27 2JB-12-16 1.1/16"X12 G1"X11 21.9 11.7 49.5 32 41 2JB-16 1.5/16"X12 G1"X11 23.1 11.7 51 36 41 2JB-20 1.5/8"X12 G1.1/4"X11 24.3 11 55.5 46 50 2JB-20-16 1.5/8"X12 G1"X11 24.3 11.7 53.5 46 41 2JB-24 1.7/8"X12 G1.1/2"X11 27.5 13 61.5 50 55 2JB-24-20 1.7/8"X12 G1.1/4"X11 27.5 11 61 50 50 Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
Pehel/2JB/Male JIC 74 Cone-Female BSP 60 Cone Straight Swivel Adapter
PEHEL Hydraulic Model: 2JB
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Straight
Thread Type: JIC/BSP
About the item:
1.Precision-machined straight hydraulic adapters with concentric thread alignment, eliminating flow turbulence and pressure drop in high-flow hydraulic loops.
2.Chamfered tube entry guides tubing for error-free assembly, reducing installation misalignment that leads to premature seal wear.
3.High Pressure Tolerance: Withstands up to 31.5MPa, suitable for heavy-load hydraulic systems.
