PART NO. THREAD DIMENSIONS E F A B L S1 S2 2JA-20 1.5/8"X12 G1.1/4"X11 24.3 10 57 46 50 2JA-24 1.7/8"X12 G1.1/2"X11 27.5 11 63.5 50 55 2JA-32 2.1/2"X12 G2"X11 34 15 74 65 70 Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
Pehel/2JA/High Pressure JIC Male-BSP Multiseal Female Straight Adapter
PEHEL Hydraulic Model: 2JA
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: Straight
Thread Type: JIC/BSP Multiseal
About the item:
1.Precision-machined straight hydraulic adapters with concentric thread alignment, eliminating flow turbulence and pressure drop in high-flow hydraulic loops.
2.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss.
3.Wide operating temperature range from -40℃ to +120℃, stable performance in extreme cold northern mines and high-temperature metallurgy workshops.
