PART NO. THREAD WELD TUBE O.D DIMENSIONS E D A B S1 1JW9-04IN 7/16"X20 1/4" 24.5 22.5 11 1JW9-06IN 9/16"X18 3/8" 26.9 22.5 14 1JW9-08IN 3/4"X16 1/2" 33 26 19 1JW9-10IN 7/8"X14 5/8" 37.8 31 22 1JW9-12IN 1.1/16"X12 3/4" 44.2 34.5 27 1JW9-16IN 1.5/16"X12 1" 48.8 41 33 1JW9-20IN 1.5/8"X12 1.1/4" 55.3 43 41 1JW9-24IN 1.7/8"X12 1.1/2" 62.5 53 48 Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
PEHEL | 90° JIC Male 74° Cone to Inch Weld Tube Adapter, Hydraulic Elbow with Weldable Tube End
PEHEL Hydraulic Model: 1JW9-IN
QTY:
Type: 90° Elbow Adapter
End 1: JIC Male 74° Cone
End 2: Inch Weld Tube
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated
About the item
1.90° JIC male 74° cone to inch weld tube adapter, designed for transitioning between JIC male threaded connections and welded tube ends in hydraulic systems.
2.JIC male end features a 74° cone sealing face, providing reliable metal‑to‑metal seal under high pressure against standard JIC female swivel nuts.
3.Weld tube end designed for permanent installation by welding to inch‑size steel tubing, creating a strong and leak‑free joint.
4.90° elbow configuration allows directional change of fluid flow in confined spaces, simplifying hydraulic circuit layout.
5.Manufactured from high‑strength carbon steel with anti‑rust surface treatment for long service life in demanding industrial environments.
