PART NO. THREAD DIMENSIONS E A B D L S1 1JW-06-14 9/16"X18 14.1 8 14 28 17 1JW-08-18 3/4"X16 16.7 10 18 35 22 1JW-12-22 1.1/16"X12 21.9 10 22 42 30 1JW-12-28 1.1/16"X12 21.9 12 28 44 30 1JW-16-28 1.5/16"X12 23 12 28 46 36 1JW-20-34 1.5/8"X12 24.3 14 34 51.5 46 1JW-32-60 2.1/2"X1 33.9 20 60 71 65 Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
PEHEL/JIC MALE 74 CONE/BUTT-WELD TUBE
PEHEL Hydraulic Model: 1JW
QTY:
JIC MALE 74 CONE/BUTT-WELD TUBE
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type 1: JIC MALE 74 CONE
Thread Type 2: BUTT-WELD TUBE
About the item:
1. Model 1JW hydraulic adapter features JIC male 74° cone end and butt‑weld tube end for permanent welded pipeline joints.
2. 74‑degree metal‑to‑metal cone sealing delivers stable leak‑proof performance complying with SAE J514 standard.
3. Wide range of UNF thread and butt‑weld tube sizes for diverse high‑pressure hydraulic tubing requirements.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, nuts and sleeves are sold separately.
5. Butt‑weld construction ensures robust connection, widely used for heavy‑duty industrial and mobile hydraulic systems.
