THREAD DIMENSIONS PART NO. E F A B S1 1ST4-02SP G1/8"×28 R1/8"X28 19 17 11 1ST4-02-04SP G1/8"X28 R1/4"X19 19.8 21 14 1ST4-04SP G1/4"X19 R1/4"×19 24 21 14 1ST4-04-02SP G1/4"X19 R1/8"×28 24.5 17.5 14 1ST4-04-06SP G1/4"X19 R3/8"×19 24.5 23 16 1ST4-04-08SP G1/4"X19 R1/2"×14 26.5 29.5 22 1ST4-06SP G3/8"X19 R3/8"×19 26 23 16 1ST4-06-04SP G3/8"X19 R1/4"X19 26 21 16 1ST4-06-08SP G3/8"×19 R1/2"X14 28.5 29.5 22 1ST4-08SP G1/2"X14 R1/2"X14 31 29.5 22 1ST4-08-06SP G1/2"X14 R3/8"×X19 30.5 25 22 1ST4-12SP G3/4"X14 R3/4""X14 34.5 30.5 27 1ST4-12-08SP G3/4"X14 R1/2"X14 34 30 27 1ST4-16SP G1"X11 R1"X11 37.5 39 33 1ST4-16-12SP G1"X11 R3/4"X14 37.5 32.5 33 1ST4-20SP G1.1/4"X11 R1.1/4"X11 44.5 44 41 1ST4-24SP G1.1/2"X11 R1.1/2"X11 47.5 47 48 1ST4-32SP G2"X11 R2"X11 54 53 63
Pehel/1ST4/45Deg Elbow Male JIS GAS 60deg Cone-Male BSPT Adapter
PEHEL Hydraulic Model: P1ST4-SP
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Elbow
Thread Type: JIS/BSPT
About the item:
1.Wide operating temperature range from -40℃ to +120℃, stable performance in extreme cold northern mines and high-temperature metallurgy workshops.
2.Durable & Corrosion-Resistant: Made of carbon steel/stainless steel with surface treatments, extending service life.
3.Chamfered tube entry guides tubing for error-free assembly, reducing installation misalignment that leads to premature seal wear.
