THREAD O-RING DIMENSIONS PART NO. E F F A B L S1 1KG-14-04 M14X1.5 G1/4"X19 O111 17 11 36 19 1KG-14-06 M14X1.5 G3/8"X19 O113 17 11.5 36.5 22 1KG-16-06 M16X1.5 G3/8"X19 O113 18 11.5 38 22 1KG-18-06 M18X1.5 G3/8"X19 O113 18 11.5 38 22 1KG-22-08 M22X1.5 G1/2"X14 O115 20 14 47 27 1KG-30-12 M30X1.5 G3/4"X14 O119 26 15.5 52.5 32 1KG-33-12 M33X1.5 G3/4"X14 O119 30 15.5 59.5 36 1KG-33-16 M33X1.5 G1"X11 O217 30 18 62 41
PEHEL | JIS Metric Male 60° Cone Hydraulic Hose Adapter | Stock Item Quick Delivery
PEHEL Hydraulic Model: P1KG
QTY:
Material: Carbon steel, Stainless Steel, Aluminium, Brass
Brand: Pehel, OEM
Color: Silver
Connector Type: Straight
Thread Type: Hydraulic Hose Adapter
1. Normal Material: Carbon Steel with Zinc Plating
2. Anti-rust performance
3. Standard or OEM service available
4. Standard thread specifications
