PART NO. THREAD DIMENSIONS E F A B L S1 S2 2KB-14-04 M14X1.5 G1/4"X19 17 5.5 34 17 19 2KB-14-06 M14X1.5 G3/8"X19 17 6.3 35.5 17 22 2KB-16-06 M16X1.5 G3/8"X19 18 6.3 36.5 17 22 2KB-18-06 M18X1.5 G3/8"X19 18 6.3 36.5 19 22 2KB-20-06 M20X1.5 G3/8"X19 20 6.3 40 22 22 2KB-20-08 M20X1.5 G1/2"X14 20 7.5 42 22 27 2KB-22-06 M22X1.5 G3/8"X19 20 6.3 40 24 22 2KB-22-08 M22X1.5 G1/2"X14 20 7.5 42 24 27 2KB-24-08 M24X1.5 G1/2"X14 21.5 7.5 45.5 27 27 2KB-24-12 M24X1.5 G3/4"X14 21.5 10.9 46.5 27 32 2KB-30-12 M30X1.5 G3/4"X14 26 10.9 52 32 32 2KB-33-16 M33X1.5 G1"X11 30 11.7 57 36 41
Metric Male 60/BSP Female 60 Cone
PEHEL Hydraulic Model: 2KB
