PARTNO. THREAD DIMENSIONS E F A B S1 1KT9-14-02SP M14X1.5 R1/8"X28 28.5 22 14 1KT9-14-04SP M14X1.5 R1/4"X19 29 25.5 14 1KT9-14-06SP M14X1.5 R3/8"X19 31 28.5 16 1KT9-16-06SP M16X1.5 R3/8"X19 31.5 28.5 16 1KT9-18-06SP M18X1.5 R3/8"X19 33.8 29.5 19 1KT9-20-06SP M20X1.5 R3/8"X19 36 30.5 19 1KT9-22-06SP M22X1.5 R3/8"X19 38 32.5 22 1KT9-22-08SP M22X1.5 R1/2"X14 38 36 22 1KT9-24-08SP M24X1.5 R1/2"X14 43.5 39.5 27 1KT9-24-12SP M24X1.5 R3/4"X14 43 43.5 27 1KT9-30-12SP M30X1.5 R3/4"X14 48 45.3 30 1KT9-33-16SP M33X1.5 R1"X11 55 50 33
Pehel/1KT9/High Pressure 90 Elbow Metric JIS Male 60 Cone-BSPT Male Hydraulic Adapter
PEHEL Hydraulic Model: 1KT9-SP
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Elbow
Thread Type: Metric JIS 60 cone/BSPT
About the item:
1.High Pressure Tolerance: Withstands up to 31.5MPa, suitable for heavy-load hydraulic systems.
2.Interchangeable with ISO 8434 standard counterparts, no custom modification required for direct replacement in existing hydraulic systems.
3.Zinc-plated carbon steel body with salt spray resistance up to 240 hours, effectively preventing corrosion in outdoor and humid working environments.
4.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss.
