PART NO. FLANGE SIZE DIMENSIONS MPa A h H C 25MPa SL-06 3/8" 40 6.2 18 35 25 SL-08 1/2" 45 6.2 20 42 SL-12 3/4" 50 6.2 22 50 SL-16 1" 65 7.5 25 62 SL-20 1.1/4" 75 7.5 30 73 SL-24 1.1/2" 90 7.5 36 85 SL-32 2" 100 9 40 98 40MPa SS-06 3/8" 40 7.2 18 35 40 SS-08 1/2" 45 7.2 20 42 SS-12 3/4" 50 8.2 22 50 SS-16 1" 65 9 25 62 SS-20 1.1/4" 75 9.8 30 73 SS-24 1.1/2" 90 12 36 85 SS-32 2" 100 12 40 98
PEHEL | ISO Square Flange | CARBON STEEL Flange
PEHEL Hydraulic Model: SL-SS
QTY:
ISO6162 square flange - PEHEL
- In hydraulic systems, PEHEL square flanges are used to connect a pipe to a component or a pipe to a pipe connection. Square flanges are, as the name suggests, square in shape. Square flanges are manufactured in accordance with various standards based on various countries in order to fulfill their purpose.
Material: Carbon steel, Stainless Steel, Aluminium, Brass
Brand: Pehel, OEM
Color: Silver
Connector Type: Square
Thread Type: Hydraulic Flange
1. Square outline design, easy positioning during installation & anti-rotation locking
2. Four-corner bolt distribution, uniform stress bearing, effectively avoid sealing surface leakage
3. Flat square surface, larger contact area than round flange, better overall sealing performance
4. Square structure matches square pipeline housings & valve bases perfectly
