FIBER OR WIRE BRAID RESIN TWIN HOSE

Model: SAE 100R7 / EN855 R7(TWIN HOSE)

QTY:

  • You May Also Like

  • Metric Size Inch Size SAE Dash Size I.D O.D. Allowed Tolerance Max W.P Min B.P (Mpa) Min B.R (mm) W.T (g/m)
    Standard Standard
    Fiber Braid Wire Braid
    mm Inches Dash mm mm mm Bar Psi Bar Psi F.B W.B F.B W.B F.B W.B
    6.3 1/4 04 6.3 12.7 ±0.10 250 3625 275 3990 100.0  110.0  50 40 220 360
    8 5/16 05 7.9 14.3  ±0.10 210 3045 250 3625 80.0  100.0  50 40 250 430
    10 3/8 06 9.5 15.9 ±0.15 175 2540 225 3260 70.0  90.0  80 50 280 480
    12.5 1/2 06 12.7 19.8 ±0.15 160 2320 185 2680 65.0  70.0  100 70 400 620
