Metric Size Inch Size SAE Dash Size I.D O.D. Max W.P Min B.P Min B.R W.T Standard Standard mm Inches Dash mm mm Mpa Bar Psi Mpa mm g/m 3 1/8 02 3.5 6.6 11 105 1522 82.7 40 65 5 3/16 03 4.8 7.9 11 105 1522 68.9 50 95 6.3 1/4 04 6.4 9.5 11 105 1522 62.0 75 120 8 5/16 05 8.0 11.1 11 105 1522 55.2 100 160 10 3/8 06 9.5 12.6 11 105 1522 48.3 125 170 12.5 1/2 08 12.9 16.1 6 56 812 41.4 165 240 16 5/8 10 16.2 19.7 6 56 812 34.5 200 280 19 3/4 12 19.0 23.6 6 56 812 27.6 230 330 22 7/8 14 22.3 26.4 6 56 812 24.1 230 390 25 1 16 25.5 29.6 6 56 812 24.1 300 460
Pehel/ SAE 100R14/PTFE Stainless Steel Wire Braided hose
PEHEL Hydraulic Model: SAE 100R14
QTY:
Material: PTFE/Stainless steel wire braided
Brand: Pehel
Application: Food industry, high and low temperature fluids, chemical industry, compressor discharge ext.
Temperature: -73℃~+260℃
About the item:
1. PTFE hose offers exceptional chemical inertness, resisting strong acids and alkalis far better than conventional rubber tubes.
2. With a wide temperature range (-70°C to +260°C), this hose maintains stable performance under extreme thermal conditions.
3. The ultra-low friction inner wall prevents material adhesion, ensuring smooth flow and easy cleaning.
4. As a stainless steel braid hose, the external braided steel layer significantly boosts pressure resistance and protects against pulsation and mechanical wear.
5. Excellent anti-aging and UV resistance give it a much longer service life than standard hoses, especially in outdoor or long-term applications.
