Metric Size Inch Size SAE Dash Size I.D W.D O.D Max W.P Min B.P Min B.R W.T Standard(mm) Lenflex(mm) Standard(mm) Lenflex(mm) Standard(mm) Lenflex(mm) mm Inches Dash Min Max Min Max Min Max Min Max Max Min Max Mpa Bar Psi Mpa mm Kg/m 6.3 1/4 04 6.1 6.9 6.2 6.8 9.6 10.8 9.6 10.4 13.5 11.5 12.5 22.5 225 3260 90.0 75 0.17 8 5/16 05 7.7 8.5 7.8 8.4 10.9 12.1 11.3 12.1 14.5 13.4 14.4 21.5 215 3120 86.0 85 0.22 10 3/8 06 9.3 10.1 9.5 10.1 12.7 14.5 13.3 14.3 16.9 15.5 16.5 18.0 180 2610 72.0 90 0.28 12.5 1/2 08 12.3 13.5 12.7 13.3 15.9 18.1 16.6 17.6 20.4 18.8 19.8 16.0 160 2320 64.0 130 0.38 16 5/8 10 15.5 16.7 15.8 16.4 19.8 21.0 19.8 20.8 23.0 22.1 23.1 13.0 130 1890 52.0 150 0.46 19 3/4 12 18.6 19.8 18.8 19.4 23.2 24.4 23.4 24.4 26.7 25.7 26.7 10.5 105 1520 42.0 180 0.57 25 1 16 25.0 26.4 25.0 25.6 30.7 31.9 30.8 31.8 34.9 33.2 34.2 8.8 88 1280 35.2 230 0.85 *31.5 1-1/4 20 31.4 33.0 31.8 32.6 —— —— 38.0 39.2 —— 40.4 41.6 7.0 70 1020 28.0 280 1.05
PEHEL | 1SC Compact One Layer Steel Wire Reinforced Hydraulic Hose, Rubber Covered High Pressure Hose
PEHEL Hydraulic Model: EN857 1SC
QTY:
Type: 1SC Hydraulic Hose
Construction: One Layer Steel Wire Braid
Cover: Rubber Covered
Standard: EN 853 Type 1SC
Brand: PEHEL, OEM
About the item:
1.1SC hydraulic hose featuring one layer of high tensile steel wire braid reinforcement, providing reliable strength for medium-pressure hydraulic applications.
2.Compact construction with smaller outer diameter compared to standard 2SC hoses, enabling installation in confined spaces.
3.Oil resistant synthetic rubber inner tube and weather resistant rubber cover for durability in hydraulic environments.
4.Manufactured in accordance with EN 853 Type 1SC standard.
5.The single wire braid reinforcement delivers flexibility while maintaining reliable pressure resistance.
