heavy tube clamp; DIN3015 standard
Clamp size Mounting rail Rail nut Cover plate Double cover palte Order code size Order code size Order code size Order code size b n b d m b d f s m b d f s m 1 PTH-E
40 22 PTH-F1 20 17.8 M10 PTH-G1 55 33 30 8 11 PHD-G1 55 33 60 8 11 2 PTH-G2 70 45 30 8 11 PHD-G21 70 45 60 8 11 3 PTH-G3 85 60 30 8 11 PHD-G3 85 60 60 8 11 4 PTH-F4
23 19.8 M12 PTH-G4 115 90 45 10 14 PHD-G4
115 90 90 10 145 265
PTH-G5 152 122 60 10 18 PHD-G5 152 122 120 10 18 6 PTH-G6 205 168 80 15 22 PHD-G6 205 168 160 15 22 7 PTH-G7 250 205 90 15 26 PHD-G7 250 205 180 15 26 8 PTH-G8 320 265 120 25 33 PHD-G8 320 265 240 25 33
Heavy Series Tube Clamp DIN 3015 – Carbon Steel Hydraulic Pipe Clamp with Weld Plate, Silver Zinc Plated
PEHEL Hydraulic Model: Heavy Tube Clamp PTH-E
QTY:
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: Clamp
Series: Heavy Series
Surface Treatment: CR3+ White Zinc Plated
About the item:
1.Full DIN 3015 Compliance – Manufactured strictly to DIN 3015 (Part 2) heavy series dimensions, guaranteeing drop-in interchangeability with any standard DIN 3015 tube clamp on the market — no redesign or retrofit needed.
2.Superior Heavy-Duty Load Capacity – The heavy series design handles large-diameter, high-pressure hydraulic pipe and shock loads that light or double series clamps cannot, making it the go-to choice for construction and mining equipment.
3.Robust Carbon Steel Construction – Machined from high-strength carbon steel available for corrosive or high-temperature environments, ensuring a long, maintenance-free service life.
4.Corrosion-Resistant Silver Zinc Plating – Protected by bright silver color zinc plating that resists rust, salt spray, and chemicals — ideal for outdoor machinery, marine hydraulic systems, and harsh industrial sites.
5.Modular Installation & OEM Flexibility – Compatible with standard weld plate, rail nut, and stacking assemblies for fast multi-line routing; supplied under the Pehel brand or customized via OEM service to match your exact size group and hardware spec.
