THREAD DIMENSIONS PART NO. E F A B S1 S2 6J9-04 7/16"X20 7/16"×20 24.5 40.4 11 17 6J9-05 1/2"X20 1/2"X20 26.6 43.7 14 19 6J9-06 9/16"×18 9/16"×18 27.7 46 14 22 6J9-08 3/4"X16 3/4"×16 34.5 53.5 19 24 6J9-10 7/8"X14 7/8"×14 39.6 60.7 22 30 6J9-12 1.1/16"×12 1.1/16"X12 45.2 67.8 27 36 6J9-14 1.3/16"×12 1.3/16"×12 48.2 69.5 30 38 6J9-16 1.5/16"×12 1.5/16"×12 50 71 33 41 6J9-20 1.5/8"X12 1.5/8"×12 57.5 79.2 41 50
PEHEL丨90° ELBOW JIC MALE 74° CONE BULKHEAD
PEHEL Hydraulic Model: P6J9/P6J9-LN
QTY:
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: Elbow Bulkhead
Thread Type: JIC
Surface Treatment: CR3+ White Zinc Plated
About the item:
· 1.Forged Construction: Ensures durability and strength for heavy-duty applications.
· 2.High Pressure Rating: Designed to withstand high-pressure hydraulic systems.
· 3. Zinc Plated Finish: Provides rust resistance and enhances longevity.
· 4. Strict tolerance crimp stem enables stable hose crimping, avoids hose pull-off & oil seepage.
· 5. Customizable Options: Available in various sizes and configurations for tailored solutions.
