PART NO. THREAD DIMENSIONS E F G A B C S1 S2 CTTB-04SP R1/4"X19 R1/4"X19 G1/4"X19 25.5 25.5 5.5 14 14 CTTB-06SP R3/8"X19 R3/8"X19 G3/8"X19 28.5 28.5 6.3 16 16 CTTB-08SP R1/2"X14 R1/2"X14 G1/2"X14 36 36 7.5 22 22 CTTB-12SP R3/4"X14 R3/4"X14 G3/4"X14 43.5 43.5 10.9 27 27 CTTB-16SP R1"X11 R1"X11 G1"X11 50 50 11.7 33 33 CTTB-20SP R1.1/4"X11 R1.1/4"X11 G1.1/4"X11 56.5 56.5 11 41 41
PEHEL | BSPT Male x BSPT Male x BSP Female 60° Tee, Hydraulic Thread Adapter with Tapered and Cone Ends
PEHEL Hydraulic Model: CTTB
QTY:
Type: Tee Adapter
End 1: BSPT Male (tapered)
End 2: BSPT Male (tapered)
End 3: BSP Female 60° Cone
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated
1.Three-way tee adapter featuring two BSPT male ends and one BSP female 60° cone end, designed for branching or combining flow in hydraulic systems.
2.BSPT male ends provide reliable sealing through tapered thread engagement when assembled with BSPT female ports.
3.BSP female 60° cone end accepts BSP male 60° cone fittings, providing metal‑to‑metal sealing through the cone angle.
4.Manufactured from high‑strength carbon steel with anti‑rust surface treatment.
5.Precision machined threads and cone seating surface ensure consistent fit and leak‑free performance.
