PART NO. THREAD DIMENSIONS E,F,G,H A,B,C,D S1 ZT-02 Rc1/8"X28 20 16 ZT-04 Rc1/4"X19 22.5 19 ZT-06 Rc3/8"X19 26 24 ZT-08 Rc1/2"X14 31 27 ZT-12 Rc3/4"X14 34 33 ZT-16 Rc1"X11 42 41 ZT-20 Rc1.1/4"X11 48 50 ZT-24 Rc1.1/2"X11 53 60 ZT-32 Rc2"X11 62 70
PEHEL/BSPT FEMALE CROSS ADAPTER
PEHEL Hydraulic Model: ZT
QTY:
BSPT FEMALE CROSS ADAPTER
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type: BSPT FEMALE
About the item:
1. ZT hydraulic fitting is straight BSPT female (Rc tapered internal thread) adapter complying with ISO 7‑1 standard.
2. Tapered‑thread engagement creates tight sealing when matched with BSPT male thread for hydraulic pipeline connections.
3. Full size range covers Rc1/8"‑Rc2" threads, covering most common British‑standard pipe connection specifications.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated surface, offering good interchangeability and anti‑corrosion performance.
5. Versatile threaded connector widely used for industrial machinery, valve manifolds and mobile hydraulic equipment assembly.
