THREAD DIMENSIONS PART NO. E F A B S1 5B9-02 G1/8"X28 G1/8"X28 22.5 20 16 5B9-04 G1/4"X19 G1/4"X19 25.5 22 19 5B9-06 G3/8"X19 G3/8"X19 30.5 26 24 5B9-08 G1/2"X14 G1/2"X14 39 31 30 5B9-12 G3/4"X14 G3/4"X14 43.5 37 33 5B9-16 G1"X11 G1"X11 50.5 43 41 5B9-20 G1.1/4"X11 G1.1/4"X11 55 46 50
Pehel/5B9/90deg Elbow Male BSP 60deg Cone-Female BSP 60deg Cone Adapter
PEHEL Hydraulic Model: P5B9
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Elbow
Thread Type: BSP 60° Cone
About the item:
1.Wide operating temperature range from -40℃ to +120℃, stable performance in extreme cold northern mines and high-temperature metallurgy workshops.
2.Chamfered tube entry guides tubing for error-free assembly, reducing installation misalignment that leads to premature seal wear.
3.Full size range from 1/4" to 1-1/4" to match various mine hydraulic pipelines
