PART NO. THREAD COPPERWASHER DIMENSIONS E F F A B L S1 S2 2TB-02-04G/SP R1/8"X28 G1/4"X19 DP-B04G 10 14.5 24.5 12 19 2TB-04G/SP R1/4"X19 G1/4"X19 DP-B04G 14.5 14.5 29 17 19 2TB-04-08G/SP R1/4"X19 G1/2"X14 DP-B08G 14.5 20 31.5 19 27 2TB-06-04G/SP R3/8"X19 G1/4"X19 DP-B04G 15 14.5 29.5 19 19 2TB-08-04G/SP R1/2"X14 G1/4"X19 DP-B04G 20 14.5 36.5 22 19 2TB-08G/SP R1/2"X14 G1/2"X14 DP-B08G 20 20 39 22 27
PEHEL | BSPT Male to BSPP Female Adapter, Hydraulic Thread Converter with Tapered Male and Parallel Female Ports
PEHEL Hydraulic Model: 2TB-G-SP
QTY:
Type: BSPT Male to BSPP Female Adapter
End 1: BSPT Male (tapered)
End 2: BSPP Female (parallel)
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated
About the item:
1.BSPT male to BSPP female adapter designed for transitioning between tapered male threads and parallel female threads in hydraulic and pneumatic systems.
2.BSPT male end features tapered threads for metal‑to‑metal sealing when connected to BSPT female ports.
3.BSPP female end accepts BSPP male fittings, with sealing typically achieved via O‑ring, bonded washer, or flat face sealing.
4.Straight body configuration allows direct inline conversion between the two thread standards.
5.Manufactured from high‑strength carbon steel with anti‑rust surface treatment for long service life.
