BSPT MALE/BSP FEMALE MULTISEAL

BSPT MALE/BSP FEMALE MULTISEAL

PEHEL Hydraulic Model: 2TA-SP

QTY:

  • BSPT MALE/BSP FEMALE MULTISEAL Specification
  • You May Also Like
  • PART NO. THREAD DIMENSIONS
    E F A B L S1 S2
    2TA-02SP R1/8"X28 G1/8"X28 10 2 28.5 12 14
    2TA-04SP R1/4"X19 G1/4"X19 14.5 4 33 17 19
    2TA-06SP R3/8"X19 G3/8"X19 15 5 35.5 19 22
    2TA-08SP R1/2"X14 G1/2"X14 20 6 43.5 22 27
    2TA-12SP R3/4"X14 G3/4"X14 20 9 47 30 32
    2TA-16SP R1"X11 G1"X11 25.5 10.5 54 36 41
    2TA-20SP R1.1/4"X11 G1.1/4"X11 26.5 10 59 46 50
    2TA-24SP R1.1/2"X11 G1.1/2"X11 26.5 11 62.5 50 55
    2TA-32SP R2"X11 G2"X11 30 15 70 65 70
