PART NO. THREAD DIMENSIONS E F G A,C B S1 S2 S3 EB-04 G1/4"X19 G1/4"X19 G1/4"X19 5.5 24.5 14 19 19 EB-06 G3/8"X19 G3/8"X19 G3/8"X19 6.3 27.5 16 22 22 EB-08 G1/2"X14 G1/2"X14 G1/2"X14 7.5 34.5 22 27 27 EB-10 G5/8"X14 G5/8"X14 G5/8"X14 9.5 35 22 30 30 EB-12 G3/4"X14 G3/4"X14 G3/4"X14 10.9 40 27 32 32 EB-16 G1"X11 G1"X11 G1"X11 11.7 46 33 41 41 EB-20 G1.1/4"X11 G1.1/4"X11 G1.1/4"X11 11 50.5 41 50 50 EB-24 G1.1/2"X11 G1.1/2"X11 G1.1/2"X11 13 57.5 48 55 55
Pehel/EB/Carbon Steel BSP 60deg Cone Female-Male-Female Swivel Tee Connector
PEHEL Hydraulic Model: EB
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Tee
Thread Type: BSP 60° Cone
About the item:
1.Instant sealing reliability – 60° cone design ensures leak-free performance under extreme pressure.
2.Wide size range from 1/4" to 2", compatible with most hydraulic hoses on the market.
3.Premium hydraulic tee fitting, perfect for construction machinery, agricultural equipment and automation lines.
4.Zinc-plated carbon steel body with salt spray resistance up to 240 hours, effectively preventing corrosion in outdoor and humid working environments.
