PART NO. THREAD DIMENSIONS E F A B L S1 S2 3BJ-04 G1/4"X19 7/16"X20 5.5 9 22 19 15 3BJ-04-05 G1/4"X19 1/2"X20 5.5 9.5 22.5 19 17 3BJ-04-06 G1/4"X19 9/16"X18 5.5 10.5 22.5 19 19 3BJ-06 G3/8"X19 9/16"X18 6.3 10.5 25 22 19 3BJ-06-04 G3/8"X19 7/16"X20 6.3 9 23.5 22 15 3BJ-06-08 G3/8"X19 3/4"X16 6.3 11 26.5 22 24 3BJ-06-10 G3/8"X19 7/8"X14 6.3 14 28 22 27 3BJ-08 G1/2"X14 3/4"X16 7.5 11 29 27 24 3BJ-08-06 G1/2"X14 9/16"X18 7.5 10.5 26 27 19 3BJ-08-10 G1/2"X14 7/8"X14 7.5 13 30 27 27 3BJ-08-12 G1/2"X14 1.1/16"X12 7.5 15 31 27 32 3BJ-10 G5/8"X14 7/8"X14 9.5 13 28.5 30 27 3BJ-12 G3/4"X14 1.1/16X12 10.9 15 32 32 32 3BJ-12-08 G3/4"X14 3/4"X16 10.9 11 30 32 24 3BJ-16 G1"X11 1.5/16"X12 11.7 16 33 41 41
Pehel | BSP Female 60° Cone to JIC Female 74° Seat Hydraulic Adapter
PEHEL Hydraulic Model: 3BJ
QTY:
- Material: Carbon steel, stainless steel
- Brand: Pehel, OEM
- Color: Silver color zinc plating
- Connector Type: Hydraulic adapter, female‑female transition fitting
- Thread Type: BSP Female 60° Cone, JIC Female 74° Seat
About the item:
- 1.Reliable BSP to JIC hydraulic adapter, precisely machined for leak‑free high‑pressure hydraulic connections.
- 2.Available in carbon steel and stainless steel material, durable for heavy‑duty industrial hydraulic systems.
- 3.Silver zinc‑plated surface delivers great anti‑corrosion performance for long service life.
- 4.Strict thread tolerance on BSP Female 60° Cone and JIC Female 74° Seat, ensures perfect fitting compatibility.
- 5.Supports Pehel standard and OEM custom service, various sizes of hydraulic adapter fittings are available.
