PART NO. THREAD DIMENSIONS E F A B S1 S2 2BJ9-04 G1/4"X19 7/16"X20 24.5 9 14 15 2BJ9-06 G3/8"X19 9/16"X18 27.5 10.5 16 19 2BJ9-08 G1/2"X14 3/4"X16 34.5 11 22 24 2BJ9-10 G5/8"X14 7/8"X14 35 13 22 27 2BJ9-12 G3/4"X14 1.1/16"X12 40 15 27 32 2BJ9-16 G1"X11 1.5/16"X12 46 16 33 41
PEHEL | 90° BSP Male 60° Seat x JIC Female 74° Seat Hydraulic Elbow Adapter
PEHEL Hydraulic Model: 2BJ9
QTY:
Type: 90° BSP Male 60° Seat / JIC Female 74° Seat Adapter
Angle: 90° Elbow
End 1: BSP Male 60° Seat
End 2: JIC Female 74° Seat
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc-plated
1.90° elbow adapter featuring a BSP male 60° seat end and a JIC female 74° seat end, designed for hydraulic systems.
2.BSP male end has a 60° seat surface that provides metal-to-metal sealing when mated with a corresponding female cone.
3.JIC female end has a 74° seat that receives a matching male cone for reliable sealing.
4.90° body configuration allows directional change of fluid flow in confined spaces.
5.Manufactured from high-strength carbon steel with anti-rust surface treatment for durability.
