PART NO. THREAD DIMENSIONS E F A B S1 S2 2TJ4-04SP R1/4"x19 7/16"x20 21 9 14 15 2TJ4-04-06SP R1/4"x19 9/16"x18 21 10.5 14 19 2TJ4-06SP R3/8"x19 9/16"x18 23 10.5 16 19 2TJ4-08SP R1/2"x14 3/4"x16 29.5 11 22 24 2TJ4-08-10SP R1/2"x14 7/8"x14 29.5 13 22 27 2TJ4-12SP R3/4"x14 1.1/16"x12 30.5 15 27 32
45 Degree BSPT Male to JIC Female 74 Seat Hydraulic Adapter
PEHEL Hydraulic Model: 2TJ4-SP
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
1. This 45 BSPT male JIC female adapter adopts standard 74 seat flared design, achieving zero leakage under high hydraulic pressure.2. Supports carbon steel and stainless steel dual materials, adapting to high-temperature and corrosion-prone industrial environments.3. Fine silver color zinc plating surface treatment enhances oxidation resistance, greatly extending fitting service life.4. Strictly calibrated BSPT male thread and JIC 74 seat ensures precise docking and smooth pipeline conversion.5. The 45° angle design of thisJIC 74 seat hydraulic fitting optimizes pipeline layout and avoids piping bending damage.
