PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH C S2 P22112-04-04 G1/4"-19 6 04 4 19 -06-05 G3/8"-19 8 05 5 22 -06-06 G3/8"-19 10 06 5 22 -08-08 G1/2"-14 12 08 6 27 -10-10 G5/8"-14 16 10 8 30 -12-10 G3/4"-14 16 10 9 32 -12-12 G3/4"-14 20 12 9 32 -16-12 G1"-11 20 12 10.5 41 -16-14 G1"-11 22 14 10.5 41 -16-16 G1"-11 25 16 10.5 41 -20-20 G1.1/4"-11 32 20 10 50 -24-24 G1.1/2"-11 40 24 11 55 -32-32 G2"-11 50 32 15 70
Pehel | BSP Female Multiseal ORFS Female Flat Seat Hydraulic Hose Fitting
PEHEL Hydraulic Model: P22112
QTY:
Orfs Female Flat Seat Hydraulic Hose Fitting
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.Dual‑end design with BSP female multiseal and ORFS female flat seat for flexible hydraulic hose connections.
- 2.Manufactured in carbon steel and stainless steel to meet different hydraulic system application scenarios.
- 3.Silver zinc‑plated surface provides great anti‑corrosion performance for long‑term fitting service life.
- 4.Precision machined ORFS female flat seat ensures zero‑leak sealing under high‑pressure hydraulic conditions.
- 5.Accurate BSP female multiseal thread delivers stable, tight connection for hydraulic hose assemblies.
