PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C S1 S2 Per hundred weight Weight per case P22611D-04-04SM G1/4"X19 6 4 23 5.5 14 19 3.5 200 P22611D-06-06SM G3/8"X19 10 6 25 6.3 17 22 5.4 100 P22611D-08-08SM G1/2"X14 12 8 28.5 7.5 22 27 80 P22611D-10-08SM G5/8"X14 12 8 30 9.5 22 30 60 P22611D-12-08SM G3/4"X14 12 8 32.1 10.9 27 32 50 P22611D-12-12SM G3/4"X14 20 12 32.5 10.9 27 32 125 P22611D-16-16SM G1"X11 25 16 36.3 11.7 32 41 28.4 60 P22611D-20-20SM G1.1/4"X11 32 20 41.5 11 41 50 30
BSP Female 60º Cone Double Hexagon
PEHEL Hydraulic Model: P22611D-SM
QTY:
BSP female 60 cone seat bsp pipe fittings for pipe galvanized steel hose fittings 22611
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.Precision BSP female 60° cone seat – the parallel-thread female cone seat matches cone-ended fittings for a tight, leak-free seal on galvanized steel pipe systems.
- 2.Galvanized steel pipe compatibility – this BSP pipe fitting threads directly onto galvanized steel pipe, simplifying plumbing and hydraulic line assembly.
- 3.Part-number traceability (22611) – the 22611 series BSP female fitting keeps standard dimensions for easy replacement and stock management.
- 4.Durable material options – silver color zinc plated carbon steel for everyday service, or stainless steel BSP pipe fittings for corrosive and marine environments.
- 5.Leak-free connections under pressure – precision-machined threads and cone seat hold stable sealing under working pressure in hydraulic and pneumatic lines.
