BSPT MALE /BSP FEMALE 60º CONE

BSPT MALE /BSP FEMALE 60º CONE

PEHEL Hydraulic Model: P2TB

QTY:

  • BSPT MALE /BSP FEMALE 60º CONE Specification
  • You May Also Like

  • PART NO.

    		THREAD DIMENSIONS
    E F A B S1 S2 L
    P2TB-02SP R1/8"-28 G1/8"-28 10 5.5 12 14 25
    -02-04 R1/8"-28 G1/4"-19 10 5.5 12 19 27
    -04 R1/4"-19 G1/4"-19 14.5 5.5 14 19 31
    -04-02 R1/4"-19 G1/8"-28 14.5 5.5 14 14 29
    -06 R3/8"-19 G3/8"-19 15 6.3 19 22 32.5
    -06-04 R3/8"-19 G1/4"-19 15 5.5 19 19 31
    -06-08 R3/8"-19 G1/2"-14 15 7.5 19 27 34
    -08 R1/2"-14 G1/2"-14 20 7.5 22 27 41
    -08-06 R1/2"-14 G3/8"-19 20 6.3 22 22 39
    -08-12 R1/2"-14 G3/4"-14 19 10.9 27 32 44
    -12 R3/4"-14 G3/4"-14 20 10.9 30 32 44
    -12-16 R3/4"-14 G 1"-11 19.5 11.7 32 41 46.5
    -16 R 1"-11 G 1"-11 25.5 11.7 36 41 52
    -20 R1.1/4"-11 G1.1/4"-11 26.5 11 46 50 57.5
    -24 R1.1/2"-11 R1.1/2"-11 26.5 13 50 55 61
    -32 R 2"-11 R 2"-11 30 16 65 70 67.5
