PART NO.
THREAD TUBE O.D DIMENSIONS E F D2 A L C S1 S2 P2BD-04-14 G1/4"X19 M14X1.5 6 12 40 1.5 19 19 P2BD-04-16 G1/4"X19 M16X1.5 8 12 40 1.5 19 22 P2BD-04-20 G1/4"X19 M20X1.5 12 12 42 2.5 19 27 P2BD-06-18 G3/8"X19 M18X1.5 10 13.5 43.5 2 22 24 P2BD-06-20 G3/8"X19 M20X1.5 12 13.5 45.5 2.5 22 27 P2BD-08-20 G1/2"X14 M20X1.5 12 16 50 2.5 27 27 P2BD-08-22 G1/2"X14 M22X1.5 14 16 50 2.5 27 27 P2BD-08-24 G1/2"X14 M24X1.5 16 16 51 2.5 27 30 P2BD-12-24 G3/4"X14 M24X1.5 16 18.5 54.5 2.5 32 30 P2BD-12-30 G3/4"X14 M30X2 20 18.5 59.5 3 32 36 P2BD-12-36 G3/4"X14 M36X2 25 18.5 60 3 36 41 P2BD-16-30 G1"X11 M30X2 20 20.5 63.5 3 41 36 P2BD-16-36 G1"X11 M36X2 25 20.5 64 3 41 41 P2BD-16-42 G1"X11 M42X2 30 20.5 67.5 5 41 50 P2BD-20-42 G1.1/4"X11 M42X2 30 20.5 69.5 5 50 50 P2BD-24-52 G1.1/2"X11 M52X2 38 23 74 6.5 55 60
PEHEL / BSP MALE 60°SEAT OR BONDED SEAL/METRIC FEMALE 24° CONE O-RING
PEHEL Hydraulic Model: P2BD
QTY:
BSP MALE 60°SEAT OR BONDED SEAL/METRIC FEMALE 24° CONE O-RING
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type 1: BSP MALE 60°SEAT OR BONDED SEAL
Thread Type 2: METRIC FEMALE 24° CONE O-RING
About the item:
1. Model P2BD hydraulic adapter features BSP male (60° seat or bonded seal) and metric female 24° cone O‑ring dual‑thread ends.
2. Dual‑sealing option of 60‑degree cone seat or bonded seal delivers flexible and reliable leak‑proof connection.
3. Wide size range covers G1/4"‑G1‑1/2" BSP threads, matching various metric tube outer diameter specifications.
4. Precisely‑machined carbon‑steel body with zinc‑plated finish, compliant with DIN2353 standard for good interchangeability.
5. Cross‑standard transition fitting widely used for industrial and mobile heavy‑duty hydraulic pipeline conversion.
