PART NO.
THREAD DIMENSIONS E F A B S1 L P1S-04 G1/4"X19 G1/4"X19 16 16 17 38 P1S-06 G3/8"X19 G3/8"X19 18 18 19 42 P1S-08 G1/2"X14 G1/2"X14 20 20 22 48 P1S-12 G3/4"X14 G3/4"X14 22 22 30 54 P1S-16 G1"X11 G1"X11 24 24 36 59
Pehel/1S/ Hydraulic JIS Gas 60Deg Cone Straight Male Hose Adapter
PEHEL Hydraulic Model: 1S
QTY:
Fetures:
JIS is equivalent to BSP thread (both tapered and parallel). But JIS has a 30° flared seat in the female variant and cone in the male variant (similar to the seat/cone system in JIC fittings)
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Straight
Thread Type: JIS GAS 60deg cone
About the item:
1.300+ bar high pressure resistance
2.Precision-machined straight hydraulic adapters with concentric thread alignment, eliminating flow turbulence and pressure drop in high-flow hydraulic loops.
3.Interchangeable with ISO 8434 standard counterparts, no custom modification required for direct replacement in existing hydraulic systems.
4.Zinc-plated carbon steel body with salt spray resistance up to 240 hours, effectively preventing corrosion in outdoor and humid working environments.
