45º BSP FEMALE

PEHEL Hydraulic Model: P3B4

QTY:

  • You May Also Like

  • PART NO.

    THREAD DIMENSIONS
    E F A B S1 S2 S3
    P3B4-04 G1/4"-19 G1/4"-19 5.5 5.5 11 19 19
    -06 G3/8"-19 G3/8"-19 6.3 6.3 14 22 22
    -06-08 G3/8"-19 G1/2"-14 6.3 7.5 19 22 27
    -08 G1/2"-14 G1/2"-14 7.5 7.5 19 27 27
    -10 G5/8"-14 G5/8"-14 9.5 9.5 22 30 30
    -12 G3/4"-14 G3/4"-14 10.9 10.9 24 32 32
    -16 G 1"-11 G 1"-11 11.7 11.7 30 41 41
