Figuring out Which Hydraulic Flange Fittings to apply
Hydraulic connections mate pipes, hoses or tubes together or to additives including cylinders, pumps, valves or ports in other gadget. They're used to make sure that they do not experience a hydraulic machine leak. These components integrate to make certain the machine is freed from leaks or different failure below high pressures. Because of certain connection configurations and programs, hydraulic flange fittings or separate flanges are the nice or on occasion the only sensible way to make an green and leak free connection.
Flange connections are typically utilized in packages a good way to stumble upon noticeably high pressures while the usage of pipe or tubing with an OD over 7/8 inches. They'll be bolted collectively to mate two sections of pipe (tube or hose ), or bolted or screwed into the issue to comfy a hydraulic flange becoming or phase of pipe. Flanges also can be disassembled for clean get entry to to adjust, easy or look at the device.
Positive flanges may also be completely welded collectively or to the port phase of the component (motor housing, valve port, and many others.). Greater typically, a flanged joint is made through bolting two flanges together with a gasket in-among to ensure a cozy seal.
There are many primary sorts of flanges:
SAE Flange L.T.
AE Split Flange Clamp 3000PSI : the marerial is 45 carbon steel. PFL is supplied as our 3000PSI hydraulic flanges.SAE Flange H.T.
SAE Split Flange Clamps 6000PSI : the marerial is 45 carbon steel. PFS is our 6000PSI hydraulic flange part no.SAE Flange
SAE Flange 3000 PSI : the marerial is 45 carbon steel. P87313 is 6000psi hydraulic flanges part no.9000PSI Flange
SAE Flange 9000 PSI : the marerial is 45 carbon steel. P87913 is supplied as 9000 PSI hydraulic flanges.JIS Flange
45º JIS FLANGE : JIS Flange Description:the marerial is 45 carbon steel. P88141 is JIS hydraulic flange type....
The hydraulic flange fittings standard is ISO 6162, which incorporates SAE Code 61 and 62 or SAE Flange 9000 PSI , along with global requirements with metric threads.
