PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C S2 20611-14-04T M14X1.5 6 04 18 5.5 17 20611-16-05T M16X1.5 8 05 19 5.5 19 20611-18-06T M18X1.5 10 06 20 5.5 22 20611-22-08T M22X1.5 12 08 22.5 6 27 20611-27-10T M27X1.5 16 10 25.5 6 32 20611-30-12T M30X1.5 22 12 27 8 36 20611-39-16T M39X2 25 16 31.7 6.5 46 20611-45-20T M45X2 32 20 31.5 8.5 50 20611-52-24T M52X2 40 24 32 10 60 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 20612-XX-XX。
PEHEL/Metric Female 60º Cone
PEHEL Hydraulic Model: P20611-T
QTY:
Metric Female 60 Degree Cone Loose Nut Fitting 20611
- 20611: metric female 60 degree cone.
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: Straight Hose Fitting
Thread Type: Metric female 60 cone
About the item:
- 1. Metric female 60° cone loose‑nut hose fitting (Model P20611‑T) for braided hydraulic hoses.
- 2. Multiple metric thread sizes and hose bore DN6‑DN40 for broad size selection.
- 3. 60‑degree cone seat delivers stable metal‑to‑metal leak‑proof sealing performance.
- 4. Precision machined dimensions, good interchangeability for hydraulic hose assembly work.
- 5. Widely used in industrial high‑pressure hydraulic fluid circuit connections.
