PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A B C S1 S2 28611-14-04PK AST M14X1.5 6 04 53 11 31 19 19 28611-18-06PK AST M18X1.5 10 06 62 11 33.5 24 24 28611-22-08PK AST M22X1.5 12 08 72 14 38 27 27
Pehel/28611PK/Straight JIS Metric Female 60° Cone Seat One Piece Fitting/Easy Installation
PEHEL Hydraulic Model: P28611-PK
QTY:
BSP Female Fittings Pipe Hose Fitting Tube Fitting
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Straight
Thread Type: Metric JIS 60deg cone
About the item:
1.JIS standard 60° cone design delivers zero-leak sealing under high pressure hydraulic working conditions
2.High-tensile carbon steel body offers excellent corrosion resistance and extended service life in harsh environments
3.Reliable Manufacturing Quality:15+ years of professional hydraulic component production experience, certified quality control system.
