PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A B C H S1 20591-16-04PK AST M16X1.5 6 04 53 31 3 32 22 20591-16-06PK AST M16X1.5 10 06 66.5 38 3 35 22 20591-18-06PK AST M18X1.5 10 06 66.5 38 3.5 38 24 20591-20-06PK AST M20X1.5 10 06 66.5 38 4 38 27 20591-24-06PK AST M24X1.5 10 06 66.5 38 3.5 41 30 20591-24-08PK AST M24X1.5 12 08 80 46 3.5 46 30 20591-30-10PK AST M30X2 16 10 90 51.2 4 55 36 20591-36-16PK AST M36X2 25 16 122 77.2 3 74 41
PEHE / 20591PKAST / Hose adapter heavy duty 90° metric female 24° Cone 0-ring H.T.
PEHEL Hydraulic Model: P20591-PKAST
QTY:
Hydraulic supplier female metric o-ring seal joint swivel elbow pipe fitting
Hydraulic One Piece Fitting Metric Female Heavy Duty Easier To Install
Material: Carbon steel
Surface Treatment: White Zinc Plating
Brand: PEHEL, OEM
Color: Silver
Connector Type: Straight
Thread: Metric
1. PEHE 20591PKAST heavy-duty 90° elbow adapter with 24° cone O-ring for leak-free hydraulic connections.
2. One-piece carbon steel construction with zinc plating ensures superior durability and corrosion resistance.
3. DIN 3865 / ISO 12151-2-compliant design delivers reliable sealing under high pressure and extreme temperatures.
4. Compatible with multiple fluid types, including oil, water, and air.
5. Metric female 24° cone with O-ring seal prevents fluid escape in demanding industrial applications.
