PEHEL/PHS3B12 MANIFOLD

PEHEL Hydraulic Model: PHS3B12

• 1. Subplate, A-B side ports 1/2”G, P-T rear ports 1/2”G, with relief valve (RV) weigh 3kg
  2. Subplate with A-B-P-T back ports, 2 fixing screw. Weigh 0.9 kg
  3. High performance  and cost effective.
  4. NPT, SAE, PT thread for all parts is available
  5. Scientific design and precise manufacturing

• ABOUT THE ITEM:




  1.PHS3B12 is standard CETOP3 single hydraulic valve subplate with 1/2" G thread ports.

  2.Two optional versions: basic 0.9kg plate and 3kg model built with integrated relief valve.

  3.Supports interchangeable NPT, SAE and PT port threads for global hydraulic systems.

  4.Precision CNC machined carbon steel base with stable high-pressure fluid performance.

  5.Compact layout with two mounting screws, cost-effective for modular valve assembly.
