PART NO. THREADE STECKO SIZE DIMENSIONS A B M N S1 2NY9-04 Z1/4"X18 1/4" 26.5 38 15.16 10.03 16 2NY9-04-06 Z1/4"X18 3/8" 30.5 42.5 20.17 14.02 22 2NY9-06 Z3/8"X18 3/8" 32.5 42.5 20.17 14.02 22 2NY9-06-08 Z3/8"X18 1/2" 36.5 46 24.16 18.03 27 2NY9-08-06 Z1/2"X14 3/8" 36.7 42.5 20.17 14.02 22 2NY9-08 Z1/2"X14 1/2" 40 46 24.16 18.03 27 2NY9-08-12 Z1/2"X14 3/4" 45.5 51.5 29.16 24.03 36 2NY9-12-08 Z3/4"X14 1/2" 44 46 24.16 18.03 27 2NY9-12 Z3/4"X14 3/4" 49 51.5 29.16 24.03 36 2NY9-12-16 Z3/4"X14 1" 56 63.5 39.12 31.01 48 2NY9-16 Z1"X11.5 1" 59 63.5 39.12 31.01 48 2NY9-20 Z1.1/4"X11.5 1.1/4" 63 63.5 46.15 38.02 48
PEHEL/90º NPT Male/stecko Female/ Adepter
PEHEL Hydraulic Model: 2NY9
QTY:
90º NPT Male/stecko Female/ Adepter
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: elbow
Thread Type: Swage Crimp End
About the item:
1. PEHEL Hydraulic’s SAE Staple Lock Hydraulic Hose Fittings with standard Stecko female ends are heavy-duty fluid connectors specially engineered for underground mining, explosion-proof workshops and marine harsh hydraulic environments.
2. SAE industrial standards, covering straight, 45-degree, 90-degree and long 90-degree elbow adapters to match all high-pressure mining hydraulic hoses.
3.Complete thread specifications are in stock for quick wholesale delivery, including NPT male, BSP male 60° seat, SAE O-ring boss male matched with Stecko female ports (model codes: 2NY, 2NY4, 2NY9, 2NY9-L, 2BY4, 2OY4-OG).
4. SAE staple lock hydraulic hose fittings, staple lock Stecko fittings, mining hydraulic connectors, carbon steel hydraulic hose adapters, Stecko female hydraulic fittings
5.Compatible with all certified hydraulic fluids used in underground mining power and drainage systems, these Stecko staple lock fittings support routine inspection, maintenance and re-certification (IMR) to extend mining machinery service life and maximize equipment uptime.
