PART NO. FLANGE SIZE HOSE BORE DIMENSIONS DN DASH A C D H L 87643-12-12 3/4" 20 12 88.5 41.3 31.7 31.8 8.9 87643-16-12 1" 20 12 90.5 47.6 38 33.2 9.6 87643-16-16 1" 25 16 99.3 47.6 38 34.7 9.6 87643-20-16 1.1/4" 25 16 104.3 54 43.6 37.5 10.4 87643-20-20 1.1/4" 32 20 117 54 43.6 41.5 10.4 87643-24-20 1.1/2" 32 20 120 63.5 50.8 45 12.7 87643-24-24 1.1/2" 40 24 134.3 63.5 50.8 49 12.7 87643-32-24 2" 40 24 140.2 79.4 66.5 54.7 12.7 87643-32-32 2" 50 32 163.5 79.4 66.5 62 12.7
PEHEL | 45° SAE Code 62 Interlock Flange Fitting, 6000 PSI High Pressure for 6 Spiral Wire Hose
PEHEL Hydraulic Model: P87643
QTY:
Stainless Carbon steel SAE 6000PSI flange, 45° elbow for use with hydraulic braided hoses
- SAE Flange Description: the marerial is 45 carbon steel. P87643 is 6000psi hydraulic flanges part no.
Type: 45° Female Flange Interlock Fitting
Pressure Rating: 6000 PSI
Hose Compatibility: 6‑wire spiral hose
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated
1.45° interlock fitting with female flange connection, designed for use with 6‑wire spiral hydraulic hoses.
2.Female flange end provides a secure, leak‑free interface when mated with corresponding male flanged components.
3.45° elbow angle allows flexible routing in tight installation spaces.
4.Manufactured from high‑strength carbon steel with anti‑rust surface treatment for durability.
5.Interlock design requires skiving of the hose, creating separate locking and sealing zones for a reliable hose assembly.
