BSP thread port and mating stud end

PEHEL Hydraulic Model: BSP thread port and mating stud end

QTY:

  • You May Also Like

  • THREAD
    d
    D1min D2
    (0+0.12)
    +0.12
    h1
    (MAX)
    H2
    (0+0.4)
    +0.4
    L2
    (MIN)
    G1/8”X28 15 11.24 0.6 1.3 10.5
    G1/4”X19 19 14.16 1.2 11.0
    G3/8”X19 23 18.86 1.9 12.5
    G1/2”X14 27 22.40 0.8 15.0
    G5/8”X14 31 26.00 2.4 16.3
    G3/4”X14 33 28.92 1.1 16.3
    G1”X11 40 35.50 19.1
    G1.1/4”X11 50 43.56 21.4
    G1.1/2”X11 56 49.42 22.5
    G2”X11 69 61.42 25.7
