PART NO. THREAD O-RING DIMENSIONS E F E F A B S1 S2 1FG9-04-02OG 9/16"X18 G1/8"X28 O011 O011 23 29 14 14 1FG9-04OG 9/16"X18 G1/4"X19 O011 O111 24 33 14 19 1FG9-04-06OG 9/16"X18 G3/8"X19 O011 O113 24 35.8 16 22 1FG9-06-04OG 11/16"X16 G1/4"X19 O012 O111 27 33.5 19 19 1FG9-06OG 11/16"X16 G3/8"X19 O012 O113 27 36.8 19 22 1FG9-06-08OG 11/16"X16 G1/2"X14 O012 O115 29 43.2 22 27 1FG9-08-06OG 13/16"X16 G3/8"X19 O014 O113 31 39 22 22 1FG9-08OG 13/16"X16 G1/2"X14 O014 O115 31 43.2 22 27 1FG9-10-08OG 1"X14 G1/2"X14 O016 O115 36.5 46.5 27 27 1FG9-10-12OG 1"X14 G3/4"X14 O016 O119 36.5 49.3 27 32 1FG9-12-08OG 1.3/16"X12 G1/2"X14 O018 O115 40.3 47.5 30 27 1FG9-12OG 1.3/16"X12 G3/4"X14 O018 O119 40.3 52 30 32 1FG9-12-16OG 1.3/16"X12 G1"X11 O018 O217 42.5 53 33 41 1FG9-16-12OG 1.7/16"X12 G3/4"X14 O021 O119 44.5 56 36 32 1FG9-16OG 1.7/16"X12 G1"X11 O021 O217 44.5 56 36 41 1FG9-20-16OG 1.11/16"X12 G1"X11 O025 O217 47.5 58 41 41 1FG9-20OG 1.11/16"X12 G1.1/4"X11 O025 O222 47.5 60 41 50 1FG9-24OG 2"X12 G1.1/2"X11 O029 O224 51.5 65.5 48 55
Pehel | 90° Elbow ORFS Male O‑Ring To BSP Male O‑Ring Hydraulic Transition Fitting
PEHEL Hydraulic Model: P1FG9-OG
QTY:
- Material: Carbon steel, stainless steel
- Brand: Pehel, OEM
- Color: Silver color zinc plating
- Connector Type: 90° Elbow, Transition adapter, ORFS Male O‑Ring, BSP Male O‑Ring
- Thread Type: ORFS Male (SAE J1453), BSP Male O‑Ring (ISO 1179‑1)
- Surface Treatment: Trivalent zinc plating, silver finish
- Sealing Type: ORFS O‑ring face seal, BSP O‑ring sealing
- Standard: SAE J1453, ISO 1179‑1
- Application: Mobile machinery, hydraulic power unit, industrial hydraulic systems
About the item:
- 1.This 90° elbow hydraulic transition piece realizes direction turn while converting ORFS male O‑ring to BSP male O‑ring port.
- 2.Carbon steel and stainless steel grades allow this hose nipple joint to fit different pressure and ambient scenarios.
- 3.Silver zinc‑plated surface delivers reliable anti‑corrosion property for this heavy‑duty hose coupling.
- 4.Accurate thread machining and O‑ring sealing faces guarantee leak‑free operation for this high‑pressure hydraulic union.
- 5.Offer Pehel standard stocks together with OEM service to satisfy your custom fluid connection component demands.
