PART NO. THREAD O-RING DIMENSIONS E F G E F G A B C S1 AF-04 9/16×18 9/16×18 9/16×18 O011 O011 O011 23 23 23 14 AF-06 11/16"×16 11/16"×16 11/16"×16 O012 O012 O012 27 27 27 19 AF-08 13/16""X16 13/16""X16 13/16""X16 O014 O014 O014 31 31 31 22 AF-10 1"X14 1"X14 1"X14 O016 O016 O016 36.5 36.5 36.5 27 AF-12 1.3/16""X12 1.3/16""X12 1.3/16""X12 O018 O018 O018 40.3 40.3 40.3 30 AF-16 1.7/16""×12 1.7/16""×12 1.7/16""×12 O021 O021 O021 44.5 44.5 44.5 36 AF-20 1.11/16""X12 1.11/16""X12 1.11/16""X12 O025 O025 O025 47.5 47.5 47.5 41 AF-24 2"X12 2"X12 2"X12 O029 O029 O029 53.5 53.5 53.5 50
Pehel | PAF | Hydraulic ORFS Male Oring Tee Adapters
PEHEL Hydraulic Model: PAF
QTY:
Material: Carbon steel
Brand: Pehel
Color: Silver
Thread: ORFS
Connector: Tee
Size: 1/4"-2"
About the items:
1. Precision adapter – designed for ORFS (O-Ring Face Seal) threaded connections.
2. ORFS thread standard – meets SAE J1453 for leak-free performance.
3. Flat face sealing – O-ring compresses against flat face for zero-leak reliability.
4. Durable steel body – corrosion-resistant for high-pressure hydraulic systems.
5. Easy installation – thread-on design with O-ring ensures quick assembly.
