90° ELBOW METRIC MALE O-RING

Model: P1EH9-OG

QTY:

  • You May Also Like

  • PART NO.

    THREAD

    O-RING

    DIMENSIONS



    E

    F

    E

    F

    A

    B

    S1

    S2



    1EH9-12-10OG

    M12X1.25

    M10X1

    8X1.9

    O08.1X1.6

    20.5

    28.5

    12

    14



    1EH9-14-12OG

    M14X1.5

    M12X1.5

    10X2

    O09.3X2.4

    22.5

    33.2

    14

    17



    1EH9-16-14OG

    M16X1.5

    M14X1.5

    11X1.9

    O11.3X2.4

    24

    36

    17

    19



    1EH9-18-16OG

    M18X1.5

    M16X1.5

    13X2

    O13.3X2.4

    26

    39

    19

    22



    1EH9-22-18OG

    M22X1.5

    M18X1.5

    16.1X2.4

    O15.3X2.4

    29

    44

    22

    24



    1EH9-27-22OG

    M27X1.5

    M22X1.5

    20.1X2.4

    O19.3X2.4

    32.5

    48

    27

    27



    1EH9-30-27OG

    M30X1.5

    M27X2

    24.1X2.4

    O23.5X3.0

    35.5

    57

    30

    32



    1EH9-36-33OG

    M36X2

    M33X2

    30X3.1

    O29.5X3.0

    42

    60.5

    36

    41



    1EH9-39-33OG

    M39X2

    M33X2

    32X3.1

    O29.5X3.0

    47.5

    64

    41

    41



    1EH9-42-42OG

    M42X2

    M42X2

    35X3.1

    O38.5X3.0

    49.5

    65

    41

    50



    1EH9-45-42OG

    M45X2

    M42X2

    38X3.1

    O38.5X3.0

    52.5

    67.5

    46

    50



    1EH9-52-48OG

    M52X2

    M48X2

    40X3.1

    O44.5X3.0

    57

    73.5

    50

    55
