THREAD DIMENSIONS PART NO. O-RING MPa E F TUBE O.D. I1 L1 L2 S1 S2 S3 1CH4-12-10OG M12X1.5 M10X1 6 O08.1X1.6 10 25 25.5 11 14 14 31.5 L 1CH4-14-12OG M14X1.5 M12X1.5 8 O09.3X2.4 11 26 30 14 17 17 1CH4-16-14OG M16X1.5 M14X1.5 10 O11.3X2.4 12.3 27.3 30.5 16 19 19 1CH4-18-16OG M18X1.5 M16X1.5 12 O13.3X2.4 13 28 34 19 22 22 1CH4-22-18OG M22X1.5 M18X1.5 15 O15.3X2.4 15 30 32 22 27 24 1CH4-26-22OG M26X1.5 M22X1.5 18 O19.3X2.4 16.5 33 40.5 27 32 27 1CH4-30-27OG M30X2 M27X2 22 O23.5X3.0 19.7 36.2 48 30 36 32 16 L 1CH4-36-33OG M36X2 M33X2 28 O29.5X30 21.5 38 42.5 36 41 41 1CH4-45-42OG M45X2 M42X2 35 O38.5X3.0 25.5 47 48 48 50 50 1DH4-14-12OG M14X1.5 M12X1.5 6 O09.3X2.4 13 28 30 14 17 17 40 S 1DH4-16-14OG M16X1.5 M14X1.5 8 O11.3X2.4 13.3 28.3 30.5 16 19 19 1DH4-18-16OG M18X1.5 M16X1.5 10 O13.3X2.4 13.5 30 34 19 22 22 1DH4-20-18OG M20X1.5 M18X1.5 12 O15.3X2.4 13.5 30 37 19 24 24 1DH4-24-22OG M24X1.5 M22X1.5 16 O19.3X2.4 16.2 34.7 40 24 30 27 1DH4-30-27OG M30X2 M27X2 20 O23.5X3.0 18.7 40.2 48 30 36 32 1DH4-36-33OG M36X2 M33X2 25 O29.5X30 21 45 49.5 36 46 41 31.5 S 1DH4-42OG M42X2 M42X2 30 O38.5X3.0 24.3 50.8 54 41 50 50 25 S
PEHEL|45°Elbow METRIC MALE HYDRAULIC HOSE ADAPTER|CARBON STEEL MATERIAL
PEHEL Hydraulic Model: P1CH4-OG P1DH4-OG/P1CH4-OG/RN P1DH4-OG/RN
QTY:
Material: Carbon steel, Stainless Steel, Aluminium, Brass
Brand: Pehel, OEM
Color: Silver
Connector Type: 45 ELBOW
Thread Type: HYDRAULIC HOSE ADAPTER
1. Stainless Steel & Carbon Steel Material Available
2. Custom non-standard connectors available, material test reports provided
3. Tested before delivery, extremely low defective rate
4. In Stock, Fast Delivery, Custom Service Supported
