PART NO. THREAD TUBE O.D. DIMENSIONS MPa E F D1 I1 L1 L2 S1 S2 1CB9-12-04 M12X1.5 G1/4"X19 6 15.5 30.5 24.5 14 14 31.5L 1CB9-14-04 M14X1.5 G1/4"X19 8 15.5 30.5 24.5 14 17 1CB9-14-06 M14X1.5 G3/8"X19 8 16.5 31.5 27.5 16 17 1CB9-16-04 M16X1.5 G1/4"X19 10 17.5 32.5 26.5 16 19 1CB9-16-06 M16X1.5 G3/8"X19 10 17.5 32.5 27.5 16 19 1CB9-16-08 M16X1.5 G1/2"X14 10 21 36 34.5 22 19 1CB9-18-04 M18X1.5 G1/4"X19 12 19 34 27.5 19 22 1CB9-18-06 M18X1.5 G3/8"X19 12 19 36 28.5 19 22 1CB9-18-08 M18X1.5 G1/2"X14 12 21 35.5 34.5 22 22 1CB9-22-06 M22X1.5 G3/8"X19 15 22 37 31 22 27 1CB9-22-08 M22X1.5 G1/2"X14 15 22 37 34.5 22 27 1CB9-26-08 M26X1.5 G1/2"X14 18 25.5 42 37.5 27 32 1CB9-30-12 M30X2 G3/4"X14 22 29.5 46 41 30 36 16L 1CB9-36-16 M36X2 G1"X11 28 33.3 49.8 47.5 36 41 1CB9-45-20 M45X2 G1.1/4"X11 35 39.2 60.7 54.5 48 50 1CB9-52-24 M52X2 G1.1/2"X11 42 44.8 67.8 63 55 60 1DB9-14-04 M14X1.5 G1/4"X19 6 17.5 32.5 24.5 14 17 60S 1DB9-16-04 M16X1.5 G1/4"X19 8 18.7 33.7 26.5 16 19 1DB9-16-06 M16X1.5 G3/8"X19 8 18.7 33.7 27.5 16 19 1DB9-18-04 M18X1.5 G1/4"X19 10 19.5 36 27.5 19 22 1DB9-18-06 M18X1.5 G3/8"X19 10 19.5 36 28.5 19 22 1DB9-18-08 M18X1.5 G1/2"X14 10 21.5 38 34.5 22 22 1DB9-20-04 M20X1.5 G1/4"X19 12 19.5 36 27.5 19 24 1DB9-20-06 M20X1.5 G3/8"X19 12 19.5 36 28.5 19 24 1DB9-20-08 M20X1.5 G1/2"X14 12 21.5 38 34.5 22 24 1DB9-22-08 M22X1.5 G1/2"X14 14 23 41 34.5 22 27 1DB9-24-06 M24X1.5 G3/8"X19 16 24 42.5 32 24 30 40S 1DB9-24-08 M24X1.5 G1/2"X14 16 24 42.5 35 24 30 1DB9-24-12 M24X1.5 G3/4"X14 16 26 44.5 40 27 30 1DB9-30-12 M30X2 G3/4"X14 20 28.3 49.8 41 30 36 1DB9-36-08 M36X2 G1/2"X14 25 32.8 56.8 42.5 36 46 1DB9-36-12 M36X2 G3/4"X14 25 32.8 56.8 43.5 36 46 1DB9-36-16 M36X2 G1"X11 25 32.8 56.8 47.5 36 46 1DB9-42-20 M42X2 G1.1/4"X11 30 36.2 62.7 50.5 41 50 1DB9-52-24 M52X2 G1.1/2"X11 38 45.8 76.8 63 55 60 31.5 S Note:In case if you are interested to order the adapter in complete set with cutting ring and nut ,it is necessary to insert suffix "RN" after our part no.,for example 1DB9-24-12RN.
Carbon Steel 90 Degree BSP Thread 60° Cone Sealing Elbow Hydraulic Fitting Zinc Plated
PEHEL Hydraulic Model: 1CB9-1DB9
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type: elbow
Thread Type:
About the item:
1. This 90 degree elbow adopts professional 60 cone sealing design, achieving zero leakage for hydraulic pipeline connection.2. Standard BSP thread machining ensures precise assembly, perfect matching with mainstream industrial pipe fittings.3. Available in carbon steel and stainless steel materials, adapting to diverse industrial and hydraulic working environments.4. Exquisite silver color zinc plating surface effectively resists oxidation and corrosion, prolonging the service life of the 90 elbow.5. Supports Pehel brand and OEM customization, meeting standardized wholesale and personalized processing demands.
