PART NO.
THREAD TUBE O.D. DIMENSIONS E F D1 D2 A B S1 L P6D-18 M18X1.5 M18X1.5 10 10 13.5 37 24 58.5 -20 M20X1.5 M20X1.5 12 12 13.5 38 27 61.5 -22 M22X1.5 M22X1.5 14 14 14 40 27 64 -24 M24X1.5 M24X1.5 16 16 14 40 30 65 -30 M30X2 M30X2 20 20 19 44 36 74 -36 M36X2 M36X2 25 25 20 47 46 80.5 -42 M42X2 M42X2 30 30 20 51 50 86 -52 M52X2 M52X2 38 38 22 55 60 92
PEHEL / Metric Male 24º H.T.bulkhead Adapter
PEHEL Hydraulic Model: P6D
QTY:
Metric Male 24º H.T.bulkhead Adapter
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: bulkhead Adapter
Thread Type: Metric Male 24º H.T.
About the item:
1. Metric Male 24° H.T. Bulkhead — through-wall adapter with metric male thread for panel or tank mounting.
2. 24° heavy-duty cone seat ensures a reliable, leak-tight DIN-style seal.
3. Available from M18x1.5 to M52x2, covering tube O.D. from 10 to 38 mm.
4. Precision-machined carbon steel construction delivers high strength and long service life.
5. Widely used in hydraulic and pneumatic systems for secure through-panel connections.
